DANNOVO Waterproof LG 324X Zoom High Speed Dome IR PTZ IP Camera+Two Group IR Leds(DN-H-PTZ3L27)
Main Features
DANNOVO Waterproof H.264 480TVLine Pan/Tilt/Zoom 150M IR Waterproof High Speed Dome IP Camera,LG 27times Optical X 12times Digital Zoom,Two Group IR Leds:6pcs big leds and 6pcs smaller IR leds(DN-H-PTZ3L27):
>Video:H.264 compression standard;
>Day & Night LG 27X optical * 12X digital (Color: 480TVL, 0.7Lux B/W: 480TVL, 0.01Lux);
>Resolution : D1(720*576),CIF(352*288),QCIF(176*144)
>Frame Ratio : NTSC 30 F/S, PAL 25 F/S;
>LG 27X Optical X 12X Digital Zoom; --(China27x Zoom,LG23x,Hitachi23x,Sony 18x Module Optional);
>IR: 120-150M;
>Horizontal Rotation Speed: 0.1 ~ 280 degrees/s;
>Supports 128 presets;
>A-B Scan:can set freely;
>A-B Scan speed:1-64 grade available;
>Dwell time:1-64s available;
>Running to preset speed:1-64 grade available;
>Supports Save Status After power Off;
>With the ability of control P/T/Z through IP network;
>Frame ratio or Bandwidth can be adjusted;
>Built-in Web server, supports remotely viewing and/or management the camera from a standard Web browser on any computer, anywhere, and at anytime;
>Each camera can Support 10 users simultaneously connected;
>Supports PPPOE and DDNS;
>Several levels of password protection;
>Supports software download and configuration online, that is convenient for camera updating and management.
Waterproof LG 324X Zoom High Speed Dome IR PTZ IP Camera Model |
DN-H-PTZ3L27 | ||||
Video Compression | H.264 Video Compression | ||||
Software | Super Client software for recording and management | ||||
Horizontal Rotation Speed | 0.1°-280°/s | ||||
Horizontal Rotation Range | 360° | ||||
Tilt Rotation Range | 90° | ||||
Auto Flip | Horizontal 180°, Vertical 90° | ||||
A-B Scan | can set freely | ||||
A-B Scan speed | 1-64 grade available | ||||
Dwell time | 1-64s available | ||||
Preset points | 128 | ||||
Running to preset speed | 1-64 grade available | ||||
Cruise Tours | 8 groups | ||||
Communication Protocol | Pelco-D,Pelco-P | ||||
Communication | RS485 | ||||
Baud Rate | 1200/2400/4800/9600bps | ||||
Privacy Mask | 2pcs (only support sony camera) | ||||
Operating Temperature | -40°- +65° | ||||
Operating humidity | ≤95% | ||||
Heater & fan | Auto temperature control | ||||
IR Distance | 100-150m | ||||
Consumption | less than 18W |
