DANNOVO Wireless Indoor IP Camera With Pan/Tilt and IR-Cut Support 2-way Audio,Mobile Phone,Motion detection(DN-H01-WS)
Main Features
DANNOVO Wireless Indoor IP Camera With Pan/Tilt and IR-Cut Support 2-way Audio,Mobile Phone,Motion detection(DN-H01-WS):
DN-H01-WS adopts H.264 Main Profile@ Level 3.0 compression format, support 2 way audio, Wifi, SD Slot (32GB), and mobile phone view, built-in Pan/Tilt and IR, alarm in and out interface, support UPNP, motion detection, email alarm, etc. It is the real all in one ip camera.
Wireless Indoor IP Camera Feature:
>32-bits RISC processor and special video encoder which can be up to 3M pixels encoding performance
>Support H.264 Main Profile@Level3.0 compression format, bit rate is smaller, and the image is more clear.It is more convenient for transferring through Internet and save more storage space
>VGA/QVGA/QQVGA resolution optional. User can change some specification according to their demands to satisfy his own visual prefer.
>Support 3 kinds of video stream, suitable for Local, Internet and Cross-platform view
>Built-in microphone, and also support to connect external audio capturing device (like MIC phone or sound pick-up)function. Audio support G.711 and G.726 types. >Built-in Pan/Tilt, horizontally 350°, vertically 100°. This equipment is smart and beautiful, very easy to install and use in many occasions.
>Support IR and color filter change automatically, no any color difference.
>Built-in web server, support video view and parameter settings by browser; use one port to send all the data, it facilitates network setting.
>Support Wireless 802.11b/g /n protocol, can build up wireless monitoring.
>Support mobile phone watching.
>Support UPNP, port forwarding automatically on the router.
>Support maxim 32G SD card for video and picture storage.
>Motion detection and alarm pin can be connected to external sensors to detect environmental situation.
>Alarming record can be stored by email, SD card, and FTP server. External alarm can be open when detecting,unusuality. It also sends alarm info to the alarm server.
>Infrared LED for night vision covers 5m area, to realize 24 hours monitoring.
>Support three level of user authority.
>Support upgrading online.
>Manufacture attached a label at the bottom of each IP Camera,it include Device ID, DDNS. When IP Camera,is connected to the internet, this URL can be used to visit the device.
>Manufacture provides free software, support Multi-view, Long time recording, video replay etc.
>Support video view by other browsers like as Firefox, safari etc.
Wireless Indoor IP Camera Model |
DN-H01-WS | |
Image Capture | Sensor | 1/4" CMOS sensor |
Total of pixel | 300k | |
Minimum illumination | IR lights on,0 Lux | |
Lens | f=4.0mm, F=2.0, Fixed Iris | |
IR_CUT | Support IR and color filter change automatically | |
Pan/Tilt | Pan Coverage | 350° |
Tilt Coverage | 100° | |
Preset Numbers | 1 | |
Assistant | Lighting Control | Auto/manual control |
Lighting | 8pcs 850nm Infrared lights, 5m distant | |
Video and Audio | First Stream Resolution | VGA/QVGA/QQVGA |
Second Stream Resolution | QVGA/QQVGA | |
Compression | H.264/JPEG | |
Frame rate | 30fps | |
First Stream Bit rate | 90kbps ~ 2.048Mbps | |
Second Stream Bit rate | 90kbps ~ 512kbps | |
Image Rotation | Flip / Mirror | |
OSD | support | |
Audio Compression | G.711/G.726 | |
Network | Basic Protocol | TCP/IP、HTTP、SMTP、FTP、DHCP、DDNS、UPNP、NTP |
Other Protocol | 802.11b/g/n | |
Other Features | Mobile Phone View | support |
Video control | support | |
Dual way audio | support | |
Memory | Snap or video into SD card | |
Browser SD card | View or download from network | |
Motion Detection | yes( 4 zone detection ) | |
Triggered Actions | Email/FTP/SD storage/external alarm/send message to alarm server | |
User Setting | Three levels | |
Date/ Time Setting | support | |
Upgrade | Upgrade from network | |
DDNS | A free DDNS provided by manufacturer | |
Hardware Interface | Ethernet | 10Base-T/100base-TX |
Memory | SD Slot | |
Alarm In | 1 way | |
Alarm Out | 1 way | |
Audio In | Internal mic x 1, audio input interface x 1 | |
Audio Out | audio output interface x 1 | |
Physical Index | Power | DC 5V |
Power consumption | <6W | |
Operating temperature | -20℃~ 50℃ | |
Humidity | 10% ~ 80% non-condensing | |
Software(PC Side) | OS Supported | Microsoft Windows 98/2000/XP/Vista etc. |
Browser | Internet Explorer6.0 and Above or Compatible Browser, Safari/Firefox etc. | |
Application Software | IPCMonitor.exe |
