Product Name:

DANNOVO Wired Indoor Security IP Camera With Pan/Tilt,IR-Cut,Support 2 way Audio,Mobile Phone,Motion detection(DN-H01)

DANNOVO Wired Indoor Security IP Camera With Pan/Tilt,IR-Cut,Support 2 way Audio,Mobile Phone,Motion detection(DN-H01)
Inquire:Wired Indoor Security IP Camera

Main Features

DANNOVO Wired Indoor Security IP Camera With Pan/Tilt,IR-Cut,Support 2 way Audio,Mobile Phone,Motion detection(DN-H01):

DN-H01 adopts H.264 Main Profile @ Level 3.0 compression format, support 2 way audio, Wifi, SD Slot (32GB), and mobile phone view, built-in Pan/Tilt and IR, alarm in and out interface, support UPNP, motion detection, email alarm, etc. It is the real all in one ip camera.



Wired Indoor Security IP Camera Features:

>32-bits RISC processor and special video encoder which can be up to 3M pixels encoding performance
>Support H.264 Main Profile@Level3.0 compression format, bit rate is smaller, and the image is more clear.It is more convenient for transferring through Internet and save more storage space
>VGA/QVGA/QQVGA resolution optional. User can change some specification according to their demands to satisfy his own visual prefer.
>Support 3 kinds of video stream, suitable for Local, Internet and Cross-platform view
>Built-in microphone, and also support to connect external audio capturing device (like MIC phone or sound pick-up)function. Audio support G.711 and G.726 types.
>Built-in Pan/Tilt, horizontally 350°, vertically 100°. This equipment is smart and beautiful, very easy to install and use in many occasions.
>Support IR and color filter change automatically, no any color difference.
>Built-in web server, support video view and parameter settings by browser; use one port to send all the data, it facilitates network setting.
>Support mobile phone watching.
>Support UPNP, port forwarding automatically on the router.
>Support maxim 32G SD card for video and picture storage.
>Motion detection and alarm pin can be connected to external sensors to detect environmental situation.
>Alarming record can be stored by email, SD card, and FTP server. External alarm can be open when detecting,unusuality. It also sends alarm info to the alarm server.
>Infrared LED for night vision covers 5m area, to realize 24 hours monitoring.
>Support three level of user authority.
>Support upgrading online.
>Manufacture attached a label at the bottom of each IP Camera,it include Device ID, DDNS. When IP Camera,is connected to the internet, this URL can be used to visit the device.
>Manufacture provides free software, support Multi-view, Long time recording, video replay etc.
>Support video view by other browsers like as Firefox, safari etc.

  Wired Indoor Security IP Camera Specifications Wired Indoor Security IP Camera Details Wired Indoor Security IP Camera Download

Wired Indoor Security IP Camera Model

DN-H01
Image Capture Sensor 1/4" CMOS sensor
Total of pixel 300k
Minimum illumination IR lights on,0 Lux
Lens f=4.0mm, F=2.0, Fixed Iris
IR_CUT Support IR and color filter change automatically
Pan/Tilt Pan Coverage 350°
Tilt Coverage 100°
Preset Numbers 1
Assistant Lighting Control Auto/manual control
Lighting 8pcs 850nm Infrared lights, 5m distant
Video and Audio First Stream Resolution VGA/QVGA/QQVGA
Second Stream Resolution QVGA/QQVGA
Compression H.264/JPEG
Frame rate 30fps
First Stream Bit rate 90kbps ~ 2.048Mbps
Second Stream Bit rate 90kbps ~ 512kbps
Image Rotation Flip / Mirror
OSD support
Audio Compression G.711/G.726
Network Basic Protocol TCP/IP、HTTP、SMTP、FTP、DHCP、DDNS、UPNP、NTP
Other Features Mobile Phone View support
Video control support
Dual way audio support
Memory Snap or video into SD card
Browser SD card View or download from network
Motion Detection yes( 4 zone detection )
Triggered Actions Email/FTP/SD storage/external alarm/send message to alarm server
User Setting Three levels
Date/ Time Setting support
Upgrade Upgrade from network
DDNS A free DDNS provided by manufacturer
Hardware Interface Ethernet 10Base-T/100base-TX
Memory SD Slot
Alarm In 1 way
Alarm Out 1 way
Audio In Internal mic x 1, audio input interface x 1
Audio Out audio output interface x 1
Physical Index Power DC 5V
Power consumption <6W
Operating temperature -20℃~ 50℃
Humidity 10% ~ 80% non-condensing
Software(PC Side) OS Supported Microsoft Windows 98/2000/XP/Vista etc.
Browser Internet Explorer6.0 and Above or Compatible Browser, Safari/Firefox etc.
Application Software IPCMonitor.exe
