DANNOVO 10X Optical Zoom IP Camera,Wired Speed Dome With PTZ+IR+SD Card +2-Way Audio(DN-H06)
Main Features
DANNOVO 10X Optical Zoom IP Camera,Wired Speed Dome With PTZ+IR+SD Card +2-Way Audio(DN-H06):
H.264 Sony CCD 480TVLine Pan/Tilt/Zoom Wired IR Speed Dome 10 times Optical Zoom IP Camera,Support 32G SD Card Storage,,Two-way Audio,with Super Client Software.
10X Optical Zoom Dome IP Camera Features:
>Video: H.264 compression standard;
>Resolution:D1(720*576),CIF(352*288),QCIF(176*144);
>Frame Ratio:NTSC 30 F/S, PAL 25 F/S;
>Audio : ADPCM compression standard;
>Two-way audio input, supports internal and external MIC auto switching,( H.264 module support audio input/output);
>H.264 module support SD card storage;
>China 10x Optical Zoom(Samsung:10 Optical X 10 Digital Optional);
>Minimum Scene Illumination: 0.05 Lux for Color/0.001Lux for B/W;
>IR: 30m; >Pan Speed: 0 ~ 280 degrees/s;
>Tilt Speed: 0 ~ 100 degrees/s;
>360 degrees continuously;
>Supports 64 presets;
>Supports 4 patrol tours;
>Supports 4 pattern tours;
>Supports Boundary scan;
>Supports Save Status After power Off;
>Supports OSD menu;
>With the ability of control P/T/Z through IP network;
>Built-in 10M/100M auto MDI/MDIX Ethernet interface;
>Frame ratio or Bandwidth can be adjusted;
>Built-in parallel I/O interface, canbe connected to external alarm sensors, supports video recording interaction with alarm message;
>Centralized network monitoring and distributed network monitoring;
>Built-in Web server, supports remotely viewing and/or management the camera from a standard Web browseron any computer, anywhere, and at anytime;
>Each camera can Support 20 users simultaneously connecte
>Supports PPPOE and DDNS;
>Several levels of password protection;
>Built-in RTOS, supports software download and configuration online, that is convenient for camera updating and management.
10X Optical Zoom IP Camera Model |
DN-H06 |
Video Compression Format | H.264 |
Image Sensor | 1/4 SONY CCD |
Vari-focal Lens | 10x times Optical Zoom |
Min Illumination | Color:0.05LUX/F1.8 B/W:0.07LUX/F1.8 |
Video Resolution | D1(720X576) ,CIF(352X288),QCIF(176X144) |
Video Frame rate | PAL:25frames/second,NTSC:30frames/second |
Infrared Distance | 25-35M |
AGC | Auto |
White Balance | Auto |
S/N Ratio | >48db |
Audio Compression | G.711 |
Audio input | 1 Channel BNC(linear input,inpedance:600) |
Audio output | MIC/BNC interface |
Network Interface | 10-100M base-t LAN RJ45 |
Network Protocol | PPPOE、TCP/IP、DHCP、UDP、RTP/RTCP、RTSP、UPNP、SMTP、SIP、DDNS、DNS |
Pan Speed | 0~280 degree/Second |
Tilt Speed | 0~100 degree/Second |
Preset Position | 64 |
Cruise Group | 4 groups |
Boundary Scanning | 4 |
Motion detection | Support |
Alarm | Support |
Software | Provide perfect platform management software, can control surveillance cameras as a complex network. |
Power supply | DC 12V |
Consumption | Less than 3w |
Working temperature | Tem:-10℃~55℃ HR:20%~80%RHG |
MTBF | 50000 hours |
