DANNOVO HD IR Wireless Dome IP Camera WIFI HD 720P 2.0 MegaPixel With IR Support Audio,SD Card,iPhone(DN-H10-MPC-IR-WS)
Main Features
DANNOVO HD IR Wireless Dome IP Camera WIFI HD 720P 2.0 MegaPixel With IR Support 2.8-12mm Manual Varifocal Lens,Audio,SD Card,iPhone,ONVIF(DN-H10-MPC-IR-WS):
DN-H10-MPC-IR-WS HD 2.0 megapixel Wireless Dome IP Camera is designed for high definition network surveillance based on Micro CMOS sensor with high-performance multimedia processor. It adopts the embedded Linux OS. It supports H.264 Main Profile, Baseline Profile, MJPEG, JPEG and so on video encoding standards. It has the advanced megapixel technology with SD card storage and picture snapshot. It can communicate with IPTV terminal devices. It is a set of video capture, image processing, video transmission, video storage, video management functions in one type of high-definition, high-performance network camera.
HD 720P 2.0 MegaPixel Wireless Dome IP Camera Features:
> 1/3" Progressive Scan CMOS sensor ;
> Support 1600x1200(15fps), 1280x960(25fps) high definition ;
> Built-in 2.8-12mm manual varifocal lens;
> Support Wirelss Wifi 802.11b/g/n;
> 16 IR LEDs,IR Distance 10m;
> H.264/MJEG is optional, dual streaming, low bandwidth,high quality;
> Support AWB, natual color,clear image;
> Build in 1 channel audio input and audio output ports, support realtime audio capture and two-way talking Audio;
> Built-in SD card slot, support SDHC card;
> Support protocals: RTSP,RTP,HTTP,TCP/IP,UDP,SMTP,PPPoE,DDNS,DNS, SNTP,DHCP,FTP;
> Support pravicy zone mask (max 4 individal mask zone);
> Alarm recording: video lost, motion detection and sensor alarm;
> Built-in Web server enables the use of a standard Web browser for viewing and management;
Wireless Dome IP Camera Model |
DN-H10-MPC-IR-WS | |||||
Hardware | ||||||
Network chip | Lan | Realtek 10/100M BASE-TX Self-adapting | ||||
Sensor | 1/3" Progressive Scan CMOS | |||||
Effective Pixels | 1600(H)×1200(V) | |||||
Min.Illumination | Color Mode:0.1Lux @(F1.2,AGC ON);B/W Mode:0Lux @(F1.2,IR ON) | |||||
Day/night | Auto,dual IR-Cut filter | |||||
IR Parameters | 16 IR LEDs,IR distance 10m | |||||
S/N | ≥50db(AGC OFF) | |||||
Auto Electronic Shutter | 1/25—1/100000sec,Slow shutter:1/2,1/4,1/8,1/12sec | |||||
Interfaces | ||||||
Optical lens | Interfaces | Φ14 | ||||
Lens | Manual zoom | |||||
Focal Length | 2.8-12mm | |||||
Audio Talkback | 1 channel MIC input, External access, 3.5 mm audio interface | |||||
Audio Output | 1 channellinear output, 3.5 mm audio interface | |||||
CVBS video output | 1 channel ,BNC connector | |||||
Storage Interface | SD card supports video storage and image snapping; SD2.0 standard,maximum storage 32G(Optional) | |||||
Network Interface | Lan | 10/100M BASE-TX,RJ-45 connector | ||||
I/O | 1-channel input, Normally Open/Normally Close modes adjustable; 1-channel output, 120VAC 1A/24VDC 1A,1 RS232 interface | |||||
Audio video encoding | ||||||
Video Compression | H.264 Main Profile; MJPEG/JPEG Baseline | |||||
Resolution | Master Streaming | 1600*1200,1-15fps/sec 1280*960,1-25fps/sec 1280*720,1-25(30)fps/sec | ||||
Second Streaming | 640*480,1-25fps/sec 320*240,1-25fps/sec 160*112,1-25fps/sec | |||||
Video Bitrate | 32Kbps~16Mbps,Supports CBR/VBR | |||||
Title OSD | Supports channel name, date, and video stream information overlay;OSD location is adjustable | |||||
Audio Compression | G.726,G.711A,G.711U,AAC,support 32 K stereo | |||||
Data transmission and storage | ||||||
Data storage | Video and Image | |||||
Recording | Recording set up to record by motion trigger,alarm trigger, manual, or schedule | |||||
Alarm Output | FTP,E-mail, Explorer, Software | |||||
Network protocol | TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP | |||||
Wireless protocols | 802.11b/g/n,Supports WEP,WPA,WPA2 | |||||
ONVIF protocol | Support | |||||
Remote View | Computer | IE 6.0 or up, max 10user | ||||
Mobile Phone | Windows Mobile,Symbian,iPhone,Android | |||||
General Parameters | ||||||
Operating Temperature | -10℃ - +55℃ | |||||
Operating Humidity | 0% - 90% | |||||
Power | DC12V | |||||
Power Consumption | 7W(MAX) |
