Product Name:

DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera,18x Optical Zoom,Support HD,SD Video Output, RS-232C, RS-422/485(DN-HDC10)

DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera,18x Optical Zoom,Support HD,SD Video Output, RS-232C, RS-422/485(DN-HDC10)
Inquire:DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera

Main Features

DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera,18x Optical Zoom,Support HD,SD Video Output, RS-232C, RS-422/485(DN-HDC10):



Main Application:

Widely used in video conferencing,Remote Teaching,Remote Medical,Church,Accident,Court,Multimedia,Chain Store,Transportation,Airport and other monitor area.



World Cheapest HDMI CVBS PTZ Video Conference Room Camera Features:



>Adopting 1/2.9’’ CMOS 2.1 Megapixel Sensor;
>2.1Megapixels 16:9 and 4:3;
>18x Optical Zoom;
>Video Format:1080p/30, 1080p/25, 720p/60, 720p/50;
>View Angle: 54.8°;
>Pan/Tilt Rotation Angle: Horizontal 355°, Vertical 120°;
>Max Pan Speed:80 degree/s; Max Tilt Speed: 60 degree/s;
>Support HDMI and CVBS(VIDEO) output, CVBS output video is better than Sony D70P;
>SD CVBS(VIDEO) can Output 16:9 and 4:3;
>PTZ Controlling Protocol: Sony VISCA, PELCO-P/D, with RS-232C, RS-422/485;
>Preset Position:9 by Remote IR Controller, 255 by Keyboard Controller;
>Remote Controller for controlling PTZ, Zoom, Preset Position etc; Two Mega pixels CMOS image sensor;
>Wide area, quiet, fast Pan/Tilt , shooting;
>New step motor with peace and fast operation,can move to appoint angle quickly and have a wide area shooting;
>New wide-angle lens with a wide Angle image capture, the best choice of small or medium meeting room.

  DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera Specifications DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera Details DANNOVO World Cheapest HDMI CVBS PTZ Video Conference Room Camera Download
Camera Model DN-HDC10
Image Sensor 1/2.9’’ CMOS
Effective Pixels Approx. 2.1 Mega pixels 16:9 and 4:3
Signal System(HD) 1080p/30, 1080p/25, 720p/60, 720p/50
Signal System(SD) PAL/NTSC
Horizontal Viewing Angle 54.8°(W)~3.4°(T)
Focus system Auto/Manual
Lens 18x Optical Zoom, f = 4.7 to 84.6mm, F1.6 to F2.7
HD Video Output HDMI
SD Video Output CVBS(VIDEO)
Minimum Illumination Color: 0.1Lux, W/B: 0.01Lux
Exposure Control Auto/Manual/Priority AE/Exposure Compensation/ Bright
Shutter Speed 1/30 ~ 1/10,000s
Gain Auto/Manual
S/N Ratio ≥50dB
Pan/Tilt Pan Angle: 355° (max. speed: 80°/s) Tilt Angle: 120° (max. speed: 60°/s)
Preset Position 9 by remote control,255 by keyboard controller
Control Protocol SONY VISCA, PELCO P/D
Camera Control Interface RS-232C, RS-422/485
Dimensions (L)153×(W)134×(H)153mm
Weight 1200g
Power 10.8V~13.0V
Operating Temperature 0℃~50℃
Storage Temperature -20℃~+60℃
Consumption 30W
