DANNOVO Wireless WIFI Pan/Tilt IP Camera With IR,Indoor Surveillance,Support 3G phone,Iphone(DN-J01-WS)
Main Features
DANNOVO Wireless WIFI Pan/Tilt IP Camera With IR,Indoor Surveillance,Support 3G phone,Iphone(DN-J01-WS):
Wireless WIFI Pan/Tilt IP Camera Features:
> Powerful high-speed video protocol processor
> MJPEG video compression
> High-sensitivity CMOS sensor
> Resolution: 640 x 480(VGA), 320 x 240(QVGA)
> Support Wireless WIFI
> Video Frame Rate: 30fps(QVGA), 15fps(VGA)
> Support two-way audio function
> Minimum Illumination: 0.5Lux F2.0
> IR night vision(Range: 10~15m)
> Remote Pan/Tilt rotate(Horizontal: 270, Vertical: 120 degree)
> Supports control P/T through IP network
> Supporting up to 4 users online simultaneously
> Bulit-in Free DDNS
> Built-in 10M/100M auto MDI/MDIX Ethernet Interface
> Flip Mirror Images: Vertical / Horizontal
> Light Frequency: 50Hz, 60Hz or Outdoor
> Multi-level users management and passwords Definition
> Built-in Web server, supports remotely viewing And/or management
the camera form a standare Web Browser on any computer,
anywhere, and at anytime
> Supporting Dynamic IP (DDNS)and UPnP LAN and Internet(ADSL,
Cable Modern)
> Giving alarm in cause of motion detection
> Supporting multiple network protocols: HTTP/ TCP/ IP/ UDP/ STMP/
DDNS/ SNTP/ DHCP/ FTP
> Built-in RTOS, supports software download and configuration online,
that is convenient for Camera updating and management
> Support Iphone,Smart Phone,3G Phone
> Built-in DDNS and Client Software
> Support IE,Firefox,Google Browser
 |
 |
 |
|
 |
|||
DANNOVO Wireless WIFI Pan/Tilt IP Camera Model.:DN-J01P-WS | ||
| Features | System security | Supports three-level account, password, user multi-level authority management |
| DDNS（free） | Built in free DDNS system,like http://demo.dannovo.hk,demo is serial code | |
| IE multi-channel view client(free) | No need to install software, support multi-channel monitor &management & check alarm picture via IE | |
| Super client | Dannovo Free Super Client Software, no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm,meeage alarm etc. | |
| Superiority | Support multi-channel monitor via cellphone or computer,certified by Microsoft activeX, support most of intelligent phone(such as Iphone,Antroid,Symbian ) | |
| CPU | Operation system | Embedded Linux OS |
| Microcomputer processor | 32Bit RSIC Embedded Processor | |
| Video | Compression format | Motion-JPEG-N |
| Signal system | CMOS 300,000 pixel | |
| Frame rate | 25fps | |
| Shutter speed | 1/50s-1/100,000s | |
| Resolution | VGA(640*480),QVGA(320*240) | |
| Image adjustment | Brightness, contrast,saturation. | |
| WB, BLC | Auto | |
| Lens | Standard 3.6mm | |
| Nightvision | Nightvision | 10Φ5 LED lights IR distance: 10m |
| Audio | Compression format | ADPCM |
| Input | Built-in Mircophone | |
| Output | one channel linear output | |
| Audio gain | AGC | |
| P/T | Motor | Built-in motor control |
| Rotation angle | Horizontal: 270° vertical: 120° | |
| Rotation speed | 11 level pan/tilt rotation speed optional, speed range 15-70°/ second | |
| Network | Network interface | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Protocol | Support TCP/IP、HTTP、ICMP、DHCP、FTP、SMTP、PPPoE etc. | |
| Wireless | WIFI,802.11 b/g/n | |
| Online visitor | Support 4 visitors at the same time | |
| IP mode | Dynamic IP address, static IP address, PPPOE | |
| Others | Shape | Cartoon robot |
| Use environment | Indoor Surveillance use | |
| Power | DC5V 2A | |
| Temperature | -10~50 °C | |
| Humidity | 95% RH | |
| Size | Item size:111*100*127mm ( L*W*H) Package size:170*170*170mm （L*W*H） | |
| Weight | G.W.: 895g（Note:for real products ） | |
| Attachment | Power adapter ,CD, manual , screws,warranty card | |
| Alarm | Input / output | 1/1 |
| Alarm detection | Built-in motion detection, sensitivity can be set | |
| Alarm action | Support Email photo ,FTP photo upload ,preset positions call , GPIOetc. | |
| System | System requirement | Microsoft Win98 SE/ME/2000/XP、Vista、Win 7, Internet Explorer 8.0, FireFox，Google Browser |
| Certification | Certificate | FCC CE SASO RoHS |
